Faber Matrix FMG3326F Instruction Manual page 40

Single-Sided Installation
A
Two-Sided Installation
A
F
C
B
G
F
C E E
D
B
G
FMG3326F
Reference
A
B
C
D
F
G (min .)
FMG4326F
Reference
A
B
C
D
F
D D
G (min .)
FMG3726L/FMG3726R
Reference
A
B
C
D
E
F
G (min .)
FMG4726L/FMG4726R
Reference
A
B
C
D
E
F
G (min .)
Wood framing Metal Framing
inches mm inches
27 686 27
44 1/4 1124 43 1/4
33 3/4 857 33 3/4
28 1/2 724 27 1/2
10 254 10
7 1/4 184 7 1/4
Wood framing Metal Framing
inches mm inches
27 686 27
54 1/8 1375 53 1/8
43 5/8 1108 43 5/8
28 1/2 724 27 1/2
10 254 10
7 1/4 184 7 1/4
Wood framing Metal Framing
inches mm inches
27 686 27
47 7/8 1216 46 7/8
42 5/8 1083 42 1/8
28 1/2 724 27 1/2
23 1/8 587 22 5/8
10 254 10
7 1/4 184 7 1/4
Wood framing Metal Framing
inches mm inches
27 686 27
57 3/4 1467 56 3/4
52 1/2 1334 52
28 1/2 724 27 1/2
23 1/8 587 22 5/8
10 254 10
7 1/4 184 7 1/4
mm
686
1099
857
699
254
184
mm
686
1349
1108
699
254
184
mm
686
1191
1070
699
575
254
184
mm
686
1441
1321
699
575
254
184
40
