Media Arrangement
4 . Install front log in the slot and pilot bracket front pin, as shown above .
5 . Position the two front small logs as shown .
5 . Place the remaining logs as shown above .
Correct
Incorrect
Correct media placement versus incorrect placement of media around pilot assembly .
63
