Chapter 4 - Specifications

Supply Voltage:
Operating Voltage:
Peak Voltage:
Reverse Battery Protection:
PWM Frequency:
Brake Voltage:
Brake Current:
Charger Connector:
Battery Charging Current:
Maximum Drive Current:
R-Net 80
R-Net 90
R-Net 120
Indicator Outputs
Lighting Outputs
Brake Light Output
Actuator Current:
- ISM
- SM
Moisture Resistance:
Operating Temperature:
Storage Temperature:
EMC tested on sample wheelchair:

Contact Magic Mobility if you require further information

3 International Court, Scoresby Vic 3179
Tel +61 3 8791 5600 Email
http://www.magicmobility.com.au
45
5940A R-net User Guide DCR1266
24Vdc
16Vdc to 35Vdc
35Vdc
-40Vdc
20kHz ± 0.5%
12/24Vdc
200µA min.
1A max.
Use only Neutrik NC3MX
12Arms max.
80A
90A
120A
42W per side
21W per side
42W total
15A max at reduced speed. 12A max at full speed.
12A max.
Electronics to IPX4
Non LCD Modules
-25°C to +50°C
-40°C to +65°C
Susceptibility:
Emissions:
ESD:
sales@magicmobility.com.au
Modules with LCD Screens
-10°C to +50°C
-20°C to +65°C
Tested at 30V/m to EN12184 and
ANSI/ RESNA requirements
To EN55022 Class B
IEC801 part 2
