6.3.8 ACTUATOR MODE
6.3.9 BLUETOOTH MODE
6.4

Message window

6.4.1 RESTART
6.4.2 TIMER
6.4.3 SLEEP
20
5940A R-net User Guide DCR1266
Displays the sections of the chair currently selected for movement,
the name given to the selection and a direction arrow showing what
sort of movement is available.
When Bluetooth Mode is entered the following screen will be
displayed.
The R-net displays warning icons and informational messages, in a
dedicated message window.
When the control system requires a reboot; for example, after a module re-
configuration, this symbol will be flashed.
This symbol is displayed when the control system is changing between different
states. An example would be entering into Programming Mode. The symbol is
animated to show the sands falling.
This symbol will be displayed for a short time before the R-net enters into a sleep
state.
