r-net user guide
2.1.2 PROFILE INDICATOR
This is an indicator that shows the selected drive profile. There may be up to 5 drive profiles available, this
depends on the programming of the control system.
2.1.3 SPEED / PROFILE DECREASE BUTTON
This button decreases the maximum speed setting or, if the control system is programmed for drive profile
operation, selects a lower drive profile.
It is possible to program the control system so this button has no effect while the wheelchair is being driven.
2.1.4 SPEED / PROFILE INCREASE BUTTON
This button increases the maximum speed setting or, if the control system is programmed for drive profile
operation, selects a higher drive profile.
2.1.5 MODE BUTTON
The Mode button allows the user to navigate through the available operating Modes for the control system.
The available modes are dependent on programming and the range of auxiliary output devices connected to
the control system.
NOTE:
When in any Mode other than Drive and Seating the Speed and Actuator LEDs are all extinguished.
2.2

Actuator Indicator

This LED set displays which Actuator channel is currently being controlled when the Control System is in
Actuator Mode
Actuator selection and operation is achieved using the Joystick.
Motions to the Left or Right select different actuator channels.
Motions Forward and Backwards move the actuator(s) selected.
3

CONTROL SYSTEM STATUS INDICATION

The battery gauge and maximum speed /profile indicator show the status of the control system.
3.1

Battery gauge is steady

This indicates that all is well.
3.2

Battery gauge flashes slowly

The control system is functioning correctly, but you should charge the battery as soon as possible.
3.3

Battery gauge steps up

The wheelchair batteries are being charged. You will not be able to drive the wheelchair until the charger is
disconnected and you have switched the control system off and on again.
3.4

Battery gauge flashes rapidly (even with the joystick released)

The control system safety circuits have operated and the control system has been prevented from moving the
wheelchair.
32
5940A R-net User Guide DCR1266 magicmobility.com.au
