Summary of Contents for Magic Mobility Extreme X8
- Page 1 Owners Manual Page 1...
-
Page 2: Power Wheelchair Owner's Manual
Magic Mobility is not liable for damage to property or personal injury arising out of unsafe use of a power chair. Magic Mobility is also not liable for any property damage or personal injury arising out of the failure of any person and/or user to following the instructions and recommendations set forth in this manual. -
Page 3: Table Of Contents
Reaching and Bending ....................9 3.15 Prescription Drugs/Physical Limitations..............9 3.16 Alcohol ........................9 Specifications........................9 The Extreme X8......................9 Features and Options ....................10 Performance Attributes ....................10 Operating Instructions......................10 Performance adjustments.................... 11 Comfort adjustments ....................11 Freewheel Mode – pushing the power chair ..............11 Electrical Safety Protection.................. - Page 4 To get the maximum range from your batteries: ..............20 Public Transportation....................20 Battery Disposal and Recycling ................... 20 Care & Maintenance ......................20 General Guidelines...................... 21 Batteries ........................21 Tires and Castors ......................21 8.3.1 Tire Inflation ......................22 8.3.2 Tire Wear ......................
-
Page 5: Safety
Using your Magic Mobility product safely also depends upon your own good judgment and/or common sense, as well as that of your provider, caregiver, and/or health professional. Magic Mobility is not responsible for injuries and/or damage resulting from any person’s failure to... -
Page 6: Weight Limitations
STOP! Trying to negotiate stairs or escalators may result in damage to your power chair. Transportation Products If it is necessary to use a transportation product such as a hoist or lift, Magic Mobility recommends that the manufacturer’s instructions and specifications are closely reviewed before using that product... -
Page 7: Stationary Obstacles: (Steps, Curbs, Etc.)
3.8.1 Maximum Recommended Incline Most public access ramps have a maximum gradient 1 in 14 (AS1428.1). Therefore, Magic Mobility recommends that the maximum slope of an incline you attempt to safely ascend or descend on your power chair does not exceed a 1 in 14 gradient. -
Page 8: Removable Parts
Removable Parts WARNING! Do not attempt to lift or move a power chair by any of its removable parts. This may result in personal injury. STOP! Do not attempt to lift or move a power chair by any of its removable parts. This may cause damage to the chair. -
Page 9: Positioning Belts
4 Specifications The Extreme X8 An Extreme X8 power chair is depicted below. This figure will help you identify some of the features referred to throughout this manual. Page 9... -
Page 10: Features And Options
Base Features and Options Every individual has different requirements and at Magic Mobility we pride ourselves on being able to meet the needs of most people. Many aspects of the power chair are customizable including, but not limited to controllers, seats, seat back recline mechanisms, armrests, headrests and leg rests. -
Page 11: Performance Adjustments
Comfort adjustments If your power chair was configured at your Magic Mobility Dealer, please consult your health care professional before changing the seat position or making any other adjustment. Some adjustments may degrade your power chair’s performance and safety by changing its center of gravity. -
Page 12: Tilt In Space Seat Option - If Fitted
Tilt in space seat option – if fitted To operate the Tilt In Space Seat: • Bring your power chair to a complete stop on a flat level surface. • Always fasten the positioning belt when operating the Tilt In Space seat. •... -
Page 13: Joystick Controls
Controller program The controller program affects speed, acceleration, deceleration, and braking. The drive mode settings are preset at the factory. If your Magic Mobility Dealer changes these settings, please make note of these changes. Page 13... -
Page 14: Hand Control Joystick Operation
WARNING! Do not attempt to reprogram your chair. Only the power chair manufacturer, an authorized representative of the manufacturer, or a trained service technician should program the controller. Hand control joystick operation 6.5.1 The Screen The status bar is located at the top of the screen. -
Page 15: System Lock
The system status is normally hidden. If a fault occurs, a wrench icon will show, together with a fault code number. Please contact your Magic Mobility Dealer should this happen. The indicator icons and side light icons will show when the lights are on. -
Page 16: Accessory Mode
Use the drive profile selection button to increase or decrease the speed profile. The selected speed profile will be shown in the center of the display 6.5.8 Accessory Mode If you are in Drive Mode, a press of the accessory mode selection button will take you to the last used accessory function, e.g. - Page 17 The On Board Programming (OBP) can be used to make the following adjustments using the joystick controller. Screen Brightness: Using either the function buttons or the joystick left/right to change the screen brightness Joystick forward/reverse or the accessory buttons accepts the new setting and returns to the main OBP menu.
-
Page 18: Lighting Mode (If Lights Fitted)
Use either the function buttons or joystick left/right to select a different digit Joystick forward increases the value of a digit Joystick reverse accepts the new settings and returns to the main OBP menu The accessory buttons cancel the new settings and returns to the main OBP menu Clock visibility: Use either the function buttons or the joystick left/right to toggle the on/off status Joystick forward accepts the new settings and returns to the main OBP menu... -
Page 19: Charging
Battery Charging We recommend using only a high quality dual rate intelligent battery charger with your Power Chair. Only use the supplied off-board charger unless otherwise approved by Magic Mobility. Do not use an automotive-type battery charger. Fully recharge any new batteries prior to use. Operate the power wheelchair around the house and grounds;... -
Page 20: To Get The Maximum Range From Your Batteries
Battery Disposal and Recycling If you encounter a damaged or cracked battery, contact your Magic Mobility Dealer for instructions on disposal. Your Magic Mobility Dealer will also have all the necessary information on battery recycling, which is our recommended course of action. -
Page 21: General Guidelines
STOP! Do not use parts, accessories, or adapters other than those authorized by Magic Mobility. This may void your warranty and cause damage to your power chair. General Guidelines Do not expose your power chair to any type of moisture at any time (rain, snow, mist, salt water, or wash). -
Page 22: Tire Inflation
TIRE INFLATION PRESSURE Min: 3.5 psi Min: 3.5 psi Max:8 psi Max:8 psi Lower tire pressures provide more traction in mud, sand and snow. For use on firmer surfaces, tire pressures may be increased up to a maximum of 8 psi depending upon the weight of the user, their preferences and driving capability. -
Page 23: Upholstery
Storage Store your Magic Mobility power chair in a warm dry environment. If you do not use your power chair regularly, it is recommended that the batteries be charged at least once per week. If you are storing your power chair for an extended period of time, please contact your Magic... -
Page 24: Weekly Checks
STOP! If any of the above checks reveal a problem, please see your Magic Mobility Dealer for repair. 8.10 Annual Checks Take your power chair to your Magic Mobility Dealer to ensure it is functioning correctly (see section 9) 9 Servicing Please contact your Magic Mobility Dealer to arrange your annual service. -
Page 25: Fault Finding
Check the batteries are charges. If the charge icon is red, put the chair on charge immediately Note if the batteries are allowed to discharge completely, they may not recharge (see section 7) in the event of this happening please contact your Magic Mobility Dealer for assistance. 10.5 Fault Codes In the case of a fault;... -
Page 26: Electromagnetic Interference (Emi) From Radio Wave Sources
Left Motor Fault – usually indicates a poor connection. Check that the motor cables are not loose or disconnected. If the above do not clear the fault, please contact your Magic Mobility dealer Right Motor Fault – usually indicates a poor connection. -
Page 27: Powered Wheelchair Electromagnetic Interference (Emi)
and police transceivers, cellular telephones, and other personal communication devices. **NOTE: Some cellular telephones and similar devices transmit signals while they are ON, even when not being used; 2) Medium-range mobile transceivers, such as those used in police cars, fire trucks, ambulance, and taxis. -
Page 28: Warranty
For more information regarding replacement units, contact your Magic Mobility Dealer. All warranties are detailed in “Terms & Conditions of Sale - Magic Mobility” (available upon request) Upon acceptance of goods at delivery the purchaser accepts the “Terms & Conditions of Sale”...
