6.3.2 CLOCK
Adjustable options are:
Visibility, whether the clock is displayed on screen.
The display format, 12 or 24 hour.
The time, the user can adjust the time.
These adjustments are made within the Settings Menu. Refer to section 8 for details.
6.3.3 SPEED DISPLAY
6.3.4 MAXIMUM SPEED INDICATOR
6.3.5 DIGITAL SPEED DISPLAY
6.3.6 LATCHED
6.3.7 INHIBIT
19
5940A R-net User Guide DCR1266
This displays the current time in a numeric format. The clock is user adjustable.
This gives a proportional display of the wheelchairs speed
This displays the current maximum speed setting.
This displays the actual speed of the wheelchair derived from the motors. The
display can be set to mph or km/h.
These adjustments can be made in the OBP Menu.
When the control system is operating in a latched condition this symbol will be
displayed.
If the speed of the wheelchair is being limited; for example, by a raised seat, then
this orange symbol will be displayed.
If the wheelchair is being inhibited from driving, then this red symbol will be
flashing.
