Electrical characteristics

5 Electrical characteristics
Table 1 TLD5190IVREG-EVAL version S01 P01 – electrical characteristics
Parameter Symbol
V
IN
Input voltage
Out voltage V
OUT
Output current I
OUT
Output power P
OUT
Switching Switching
frequency frequency
PWM frequency PWM
System efficiency Eff
User Manual
2020-07-22
Value
Min. Typ. Max.
5.5 -
5.5
–
5.5
150 –
0 –
– –
– 385
100 –
freq
– 95
Unit Note/Test Condition
35 V
Power derating may occur for
41,8 LED driver mode
V
22.5 Voltage mode
1500 mA LED driver mode (up to 6 A by changing RSHO)
6 A Voltage mode
V
12 V to 35 V, T
IN
60 W
JIIN closed
50 W
JIIN open (input current limiter ON)
see Figure 10 for power derating curve
– kHz Spread spectrum deviation is present
500 Hz
Measured in voltage mode
– %
V
= 12 V, V
IN OUT
8 of 12
V
< 12 V
IN
= 25°C
A
= 15 V, I = 3 A
OUT
