TLD816KAURXCB_EVAL
LITIX™ Pixel Front
User guide

About this document

This board is designed to drive and supply the Nichia light source NMAWA16KAT, composed of the Nichia LED
matrix and the Infineon ASIC drive TLD816K. The NMAWA16KAT is a high-definition LED matrix light source
featuring 16 384 pixels, equipped with a built-in driver IC for LED drive. The brightness of each LED can be
independently controlled. The board can be used for high-definition ADB, ADAS-related information projection
or message display for automotive headlights.
The light source can be tested on a load board that is fully compatible with TLD816KAURXCB_EVAL.
To receive a load board with the light source already soldered, contact your Nichia sales representative.
The core of this board is an automotive-grade Infineon AURIX™ SAK-TC377TX-96F300S AB that belongs to
the TC37xTX family. In terms of performance, theTC37xTX family offers three TriCore™ running at 300 MHz and
up to 4.3 MBytes embedded RAM, and consumes less than 2 W. This model supports floating point and fix point
with all cores. It features 6 MB flash/ECC protection and 3 MB SRAM/ECC protection, 2x Gbit Ethernet, 12x CAN
FD, 1x FlexRay, 12x LINs, 5x QSPI, 1x I²C, 15x SENT, 5x PSI, 1x HSSL, 2x MSC and 1x eMMC.
AURIX™ TC37xTX family is best-in-class performance enabling ASIL-D designs.
The board is also equipped with two DC-DC converters to supply separately the power and logic stages of the
light source.
Scope and purpose
The scope of this user guide is to provide instructions on the use of the TLD816KAURXCB_EVAL board.
Intended audience
This document is intended for engineers who perform measurements and check performances with the
TLD816KAURXCB_EVAL board.
Evaluation board
This board is to be used during the design-in process for evaluating and measuring characteristic curves, and
for checking datasheet specifications.
PCB and auxiliary circuits are NOT optimized for final customer design.
User guide
Please read the sections "Important notice" and "Warnings" at the end of this document
Rev.1.00
www.infineon.com
2024-07-19
