Banner Engineering Corp.

Minneapolis, U.S.A.

•

www.bannerengineering.com • Tel: 763.544.3164

106.0 mm

(4.17")

96.0 mm

(3.78")

5.0 mm

(0.20")

69.0 mm

(2.72 ")

5.5 mm

(0.22")

Figure 2-2. Control module dimensions

Specifications

115.0 mm

(4.53")

81.0 mm

(3.19")

35.0 mm

(1.38")

DIN mounting slot

Slot for M3.5 screws (2)

P/N 64118 rev. B
