INSTRUCTION MANUAL
HYBRID IP TRANSCEIVER
IP730D
IP740D
INTRODUCTION
1
ACCESSORIES
2
BEFORE USING
3
USING THE CELLULAR MODE
4
USING THE IDAS MODE
5
OTHER FUNCTIONS
6
SET MODE
7
FOR YOUR REFERENCE

Advertisement

loading
Need help?

Need help?

Do you have a question about the IP730D Lite and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Icom IP730D Lite

  • Page 1 INSTRUCTION MANUAL INTRODUCTION ACCESSORIES HYBRID IP TRANSCEIVER BEFORE USING IP730D USING THE CELLULAR MODE IP740D USING THE IDAS MODE OTHER FUNCTIONS SET MODE FOR YOUR REFERENCE...
  • Page 2 Icom Inc. is under license. contamination. AQUAQUAKE is a trademark of Icom Incorporated. • The use of Icom transceivers with any equipment that is All other products or brands are registered trademarks or not manufactured or approved by Icom.
  • Page 3 Section ACCESSORIES Supplied accessories1-2 Attachable accessories1-2 D Antenna 1-2 D Battery pack/Battery case 1-3 D Belt clip 1-3...
  • Page 4 ACCESSORIES Supplied accessories Battery pack Belt clip Connector cover and screw NOTE: Some accessories are not supplied, or the shape is different, depending on the transceiver version. Attachable accessories D Antenna Connect an optional antenna to the antenna connector CAUTION: •...
  • Page 5 ACCESSORIES Attachable accessories D Battery pack/Battery case CAUTION: • DO NOT attach or detach the battery pack or the battery case when the transceiver is wet or soiled This may result in water or dust getting into the transceiver, battery pack, or battery case and may damage them •...
  • Page 6 Section BEFORE USING Panel description ������������������������������������������������������������������������������������2-2 D Front, top and side panels ��������������������������������������������������������������2-2 D Status indicator �������������������������������������������������������������������������������2-2 D Multi-connector �������������������������������������������������������������������������������2-2 D About the assignable key functions ������������������������������������������������2-2 Function display��������������������������������������������������������������������������������������2-3 D Cellular mode ����������������������������������������������������������������������������������2-3 D IDAS mode �������������������������������������������������������������������������������������2-3 D Cellular/IDAS mode ������������������������������������������������������������������������2-3 Basic operation ���������������������������������������������������������������������������������������2-4 D Turning ON the transceiver �������������������������������������������������������������2-4 D Adjusting the volume level ��������������������������������������������������������������2-4...
  • Page 7 BEFORE USING Panel description D Front, top and side panels D Multi-connector Connects to an optional speaker microphone or headset� Rotary Selector L Turn OFF the transceiver before attaching or detaching the microphone� Antenna [VOL] Connector CAUTION: DO NOT use the transceiver without the Status connector cover or optional equipment attached�...
  • Page 8 BEFORE USING Function display IDAS mode Cellular mode D Cellular mode D Cellular/IDAS mode Displays the signal strength level by 3 bars� • Displayed when the Voice Recorder L A connected network type (4G or 3G) is function is ON� (p� 5-10) displayed on the left top�...
  • Page 9 BEFORE USING Basic operation D Turning ON the transceiver NOTE: Before using the transceiver for the first time, the battery pack must be fully charged for optimum life and operation� See the BATTERY CHARGING section on the boxed INSTRUCTIONS� z Rotate [VOL] clockwise to the 12 o’clock position to turn ON the transceiver� L The dial is made tight for dust and water resistance�...
  • Page 10 Section USING THE CELLULAR MODE Basic operation ��������������������������������������������������������������������������������������3-2 D Operating keys ��������������������������������������������������������������������������������3-2 D Receiving and Transmitting ������������������������������������������������������������3-3 Advanced operation��������������������������������������������������������������������������������3-4 D About the Talkgroup Call �����������������������������������������������������������������3-4 D Selecting a Talkgroup number ��������������������������������������������������������3-5 D Sending a message (Message Call) �����������������������������������������������3-6 D Browsing received messages ���������������������������������������������������������3-7 D Status Call ��������������������������������������������������������������������������������������3-7 D Toggling the SIM card ���������������������������������������������������������������������3-8 D Pocket Beep function ����������������������������������������������������������������������3-8...
  • Page 11 USING THE CELLULAR MODE Basic operation D Operating keys Rotary Selector Rotary Rotate to select a channel or scroll Selector the screen� [Emer] Hold down until “Emergency” is [VOL] displayed to send an Emergency call� (p� 5-6) [Emer] [PTT] Hold down to transmit, release to receive�...
  • Page 12 USING THE CELLULAR MODE Basic operation D Selecting a call-to party 1� Push [Address] to display the Address book� L The Address book is displayed� 2� Push [Address] several times to toggle the call type� L The selectable call type may differ, depending on a presetting. 3�...
  • Page 13 USING THE CELLULAR MODE Advanced operation D About the Talkgroup Call The Talkgroup Call function enables the user to communicate with call-to parties in the same Talkgroup� For example, in the illustration below, when the transceiver “00105” in its normal group “10002” selects Talkgroup “20001,”...
  • Page 14 USING THE CELLULAR MODE Advanced operation D Selecting a Talkgroup number You can select a Talkgroup number if the Talkgroup Call function is assigned to the [FUNC] key� Ask your dealer for details� 1� Push [FUNC] to display the Function� •...
  • Page 15 USING THE CELLULAR MODE Advanced operation D Sending a message (Message Call) You can send a message, depending on a presetting� Ask your dealer for details� 1. Selecting a call-to party 1� Push [Address] to display the Address book� • The Address book is displayed� 2�...
  • Page 16 USING THE CELLULAR MODE Advanced operation D Browsing received messages You can browse received messages, depending on a presetting� Ask your dealer for details� 1� Push [Call History] to display the Call history� • The Call history is displayed� 2� Push [Call History] to display “Rx MSG log�” L You may need to push [Call History] several times, depending on a presetting�...
  • Page 17 USING THE CELLULAR MODE Advanced operation D Toggling the SIM card The transceiver has two SIM card slots, SIM 1 and SIM 2� You can toggle which SIM card to use in the Detailed Set mode� 1� Turn OFF the transceiver, if it is turned ON� 2�...
  • Page 18 Section USING THE IDAS MODE Basic operation ���������������������������������������������������������������������������������������4-2 D Operating keys ��������������������������������������������������������������������������������4-2 D Selecting a Zone �����������������������������������������������������������������������������4-3 D Selecting a channel ������������������������������������������������������������������������4-3 D Receiving and transmitting �������������������������������������������������������������4-3 D Transmitting Notes ��������������������������������������������������������������������������4-3 Other functions ���������������������������������������������������������������������������������������4-4 D Radio Access Number (RAN) ���������������������������������������������������������4-4 D Encryption function �������������������������������������������������������������������������4-4...
  • Page 19 USING THE IDAS MODE Basic operation D Operating keys Rotary Selector Rotary Rotate to select a channel or scroll Selector the screen� [Emer] Hold down until “Emergency” is [VOL] displayed to send an Emergency call� (p� 5-6) [Emer] [PTT] Hold down to transmit, release to receive�...
  • Page 20 USING THE IDAS MODE Basic operation D Selecting a Zone D Transmitting Notes Certain channels are grouped together and assigned Transmit Inhibit function to a Zone according to their intended use� The transceiver has several inhibit functions which For example, Analog channels ‘Station 1’ and ‘Station restrict transmission under the following conditions: 2’...
  • Page 21 USING THE IDAS MODE Other functions D Radio Access Number (RAN) D Encryption function Radio Access Number (RAN) is a signaling system The Encryption function enables voice scrambling, designed for digital radio communications� When a which provides private digital communication between channel is set up with a RAN, the squelch will open stations�...
  • Page 22 Section OTHER FUNCTIONS Using a Bluetooth ® device ����������������������������������������������������������������������5-2 D About the VS-3 Bluetooth headset �������������������������������������������������5-2 D Pairing with a Bluetooth device �������������������������������������������������������5-3 D Settings for the Bluetooth function ��������������������������������������������������5-3 D Disconnecting a paired device ��������������������������������������������������������5-4 D Deleting a Bluetooth device from the pairing list �����������������������������5-4 D Initializing the Pairing lists ���������������������������������������������������������������5-5 Using the Emergency call function ���������������������������������������������������������5-6 D The Man Down function ������������������������������������������������������������������5-7...
  • Page 23 OTHER FUNCTIONS Using a Bluetooth device ® NOTE: Connect with a device that complies with the standards set by Bluetooth SIG and has been certified. Even if the device complies with the Bluetooth standard, it may not be able to connect to the transceiver, depending on the specifications and settings of the device, and not all operations are guaranteed.
  • Page 24 Search BT Device • If found, the device’s name and BD address are displayed on the screen� ICOM BT-002 (Example: ICOM BT-002) Search BT Device 2� Push [▲] or [▼] to select the headset to pair and connect, and then push Connect [Call History]�...
  • Page 25 Pairing List • “Unconnected” is displayed if the headset or device is correctly disconnected� L Do the same steps to reconnect to the Bluetooth device� ICOM BT-002 Unconnected D Deleting a Bluetooth device from the pairing list You can delete Bluetooth devices from the “Pairing List” screen�...
  • Page 26 OTHER FUNCTIONS Using a Bluetooth device ® D Initializing the Pairing lists If you have problems with Bluetooth operation, initialize the pairing lists, as shown below� Initializing the Pairing list of the transceiver L All the paired Bluetooth devices are deleted from the Pairing list by the initialization� L The Pairing list is not initialized by the RESET function in the Detailed Set mode�...
  • Page 27 • Returns to the Standby screen when you release [PTT]� NOTE: The Emergency function may not properly work, depending on the surrounding environment such as obstructions, weather condition, and so on� Icom is not responsible for the destruction or damage caused by using the Emergency Call function�...
  • Page 28 Emergency mode is canceled. NOTE: The Man down function may not properly work, depending on the surrounding environment such as obstructions, weather condition, and so on� Icom is not responsible for the destruction or damage caused by using the Man Down function�...
  • Page 29 Emergency mode is canceled. NOTE: The Lone Worker function may not properly work, depending on the surrounding environment such as obstructions, weather condition, and so on� Icom is not responsible for the destruction or damage caused by using the Lone Worker function�...
  • Page 30 Icom is not responsible for the destruction or damage Icom is not responsible for the destruction or damage caused by using the Stationary Detection function� caused by using the Motion Detection function�...
  • Page 31 OTHER FUNCTIONS Using the Voice Recorder function The transceiver can record and playback up to 10 of the latest incoming calls, depending on a presetting� L Records up to 4 minutes per call� If a call is longer than 4 minutes, the older will be automatically deleted�...
  • Page 32 OTHER FUNCTIONS Using assignable keys Functions shown below may be assigned to the [Sub PTT], [Side 1], and [Side 2] keys, depending on a presetting� Hold down or push these keys to use assigned functions� You can also assign these functions in the Detailed Set mode (p�...
  • Page 33 OTHER FUNCTIONS Using the Dual mode You can use the Cellular mode and IDAS mode at the same time� D Main mode and Sub mode When the Dual mode is selected, the Main mode and Sub mode are displayed as shown to the right� Main mode Sub mode Switching the operating mode:...
  • Page 34 Section SET MODE Using the Set mode ��������������������������������������������������������������������������������6-2 D Basic Set mode �������������������������������������������������������������������������������6-2 D Detailed Set mode ��������������������������������������������������������������������������6-2 D Using the Set mode ������������������������������������������������������������������������6-2 Set mode items���������������������������������������������������������������������������������������6-3 D Common �����������������������������������������������������������������������������������������6-3 D Dual ������������������������������������������������������������������������������������������������6-8 D Cellular ��������������������������������������������������������������������������������������������6-9 D IDAS ��������������������������������������������������������������������������������������������� 6-11...
  • Page 35 SET MODE Using the Set mode You can use the Set mode to set infrequently changed values or function settings� The transceiver has 2 types of Set modes, as shown below� L You cannot transmit or receive while the transceiver is in the Set mode� D Basic Set mode 1�...
  • Page 36 SET MODE Set mode items The shaded items are also displayed in the Basic Set mode� L Items or default values may be differ, depending on the transceiverʼs version or presettings. Ask your dealer for details. D Common Item Description Option/range Default LOG CLEAR...
  • Page 37 SET MODE Set mode items The shaded items are also displayed in the Basic Set mode� L Items or default values may be differ, depending on the transceiverʼs version or presettings. Ask your dealer for details. D Common Item Description Option/range Default Man Down*...
  • Page 38 SET MODE Set mode items The shaded items are also displayed in the Basic Set mode� L Items or default values may be differ, depending on the transceiverʼs version or presettings. Ask your dealer for details. D Common Item Description Option/range Default Side 1 Push...
  • Page 39 SET MODE Set mode items The shaded items are also displayed in the Basic Set mode� L Items or default values may be differ, depending on the transceiverʼs version or presettings. Ask your dealer for details. D Common Item Description Option/range Default BT PTT &...
  • Page 40 SET MODE Set mode items The shaded items are also displayed in the Basic Set mode� L Items or default values may be differ, depending on the transceiverʼs version or presettings. Ask your dealer for details. D Common Item Description Option/range Default Init BT Unit*...
  • Page 41 SET MODE Set mode items The shaded items are also displayed in the Basic Set mode� L Items or default values may be differ, depending on the transceiverʼs version or presettings. Ask your dealer for details. D Dual Item Description Option/range Default Cellular Call Tone...
  • Page 42 SET MODE Set mode items The shaded items are also displayed in the Basic Set mode� L Items or default values may be differ, depending on the transceiverʼs version or presettings. Ask your dealer for details. D Cellular Item Description Option/range Default Success Tone...
  • Page 43 SET MODE Set mode items The shaded items are also displayed in the Basic Set mode� L Items or default values may be differ, depending on the transceiverʼs version or presettings. Ask your dealer for details. D Cellular Item Description Option/range Default Echo Canceller...
  • Page 44 SET MODE Set mode items L Items or default values may be differ, depending on the transceiverʼs version or presettings. Ask your dealer for details. D IDAS Item Description Option/range Default SQL Level Selects whether or not to display the ON or OFF Squelch level adjustment screen by pushing [FUNC]�...
  • Page 45 Section FOR YOUR REFERENCE Specifications ����������������������������������������������������������������������������������������7-2 D General �������������������������������������������������������������������������������������������7-2 D 4G (LTE)/3G (W-CDMA) ����������������������������������������������������������������7-2 D IDAS �����������������������������������������������������������������������������������������������7-3 D Transmitter ��������������������������������������������������������������������������������������7-3 D Receiver ������������������������������������������������������������������������������������������7-4 D Bluetooth �����������������������������������������������������������������������������������������7-4 Options ��������������������������������������������������������������������������������������������������7-5 D Battery pack/Battery case ���������������������������������������������������������������7-5 D Chargers �����������������������������������������������������������������������������������������7-5 D Antennas �����������������������������������������������������������������������������������������7-5 D Others ���������������������������������������������������������������������������������������������7-5 D About the Side Tone function and headset �������������������������������������7-6 D Using the BC-227 desktop charger ��������������������������������������������7-6 D Using the BC-226 desktop charger ��������������������������������������������7-7...
  • Page 46 FOR YOUR REFERENCE Specifications L Measurements made without an antenna� L All stated specifications are subject to change without notice or obligation� D General • Antenna impedance (For IDAS): 50 Ω nominal • Input impedance (MIC): 2�2 k Ω • Output impedance (audio): 8 Ω...
  • Page 47 FOR YOUR REFERENCE Specifications D IDAS • Frequency range: IP730D 136 MHz ~ 174 MHz IP740D 350 MHz ~ 470 MHz • Number of conventional channels: 128 ch / 8 Zone • Type of emission: 16K0F3E (25�0kHz), 8K50F3E (12�5kHz), 4K00F1E, 4K00F1D (6�25 kHz) D Transmitter •...
  • Page 48 FOR YOUR REFERENCE Specifications D Receiver • Sensitivity: 0�0 dBuVemf maximum (at 20 dB SINAD) –2�0 dBuVemf typical (at 20 dB SINAD) • Adjacent channel selectivity: IP730D 60 dB minimum, 67 dB typical (Narrow) 70 dB minimum, 72 dB typical (Wide) 50 dB minimum, 62 dB typical (Digital) IP740D 60 dB minimum, 67 dB typical (Narrow)
  • Page 49 FOR YOUR REFERENCE Options D Battery pack/Battery case • FA-SC26US/FA-SC73US uhf stubby antennas FA-SC26US 400–450 MHz • BP-303 battery pack FA-SC73US 450–490 MHz Voltage Capacity Approximate • FA-SC61UC uhf cut antennas operating time* FA-SC61UC 380–520 MHz 7�2 V 3200 mAh (Minimum) 24 hours (Cellular mode) •...
  • Page 50 FOR YOUR REFERENCE Options D About the Side Tone function and headset The Side tone function (p� 6-9) works differ depending on the connected microphone, as shown below� L Usable options may be added in the future� Ask your dealer for details of how they work� When the HM-238MC or VS-5MC is attached: The transceiver always outputs your voice to a headset�...
  • Page 51 FOR YOUR REFERENCE Options D Using the BC-226 desktop charger Charging time: approximately 4�2 hours for the BP-303� Battery pack Turn OFF CAUTION: Before using the charger, read the ‛Battery caution’ and ‛Charging caution’ on the INSTRUCTIONS that boxed with the transceiver� Status indicator Light color Status...
  • Page 52 FOR YOUR REFERENCE Options D Using the BP-305 battery case Install 5 × AA (LR6) size alkaline batteries, as shown below� 4� Insert the battery holder to the battery case until 1� Open the battery case� the tab makes a ‘click’ sound� 2�...
  • Page 53 FOR YOUR REFERENCE Options D Using the LC-195 carrying case The LC-195 is a leather case that is usable when the battery pack is attached� Adjust the fixing position with the hook-and-loop fasteners� Attach an optional MB-57L shoulder strap if necessary Hook-and-loop fastener Adjust here You can charge even when the leather case is attached, as shown below�...
  • Page 54 FOR YOUR REFERENCE Options D Using the HM-238MC tiepin type microphone with a [Sub PTT] switch The HM-238MC is a Tie-clip type microphone that can operate the [PTT], [Sub PTT], and [Side 1] switches of the transceiver� NOTE: When the HM-238MC is attached to the transceiver, no audio is output from the transceiver’s speaker� BE SURE to connect the EH-15B, SP-26, or SP-28 earphones to the HM-238MC before use�...
  • Page 55 FOR YOUR REFERENCE Options D Using the HM-245T dtmf speaker microphone The HM-245T is the microphone that has Ten-keypad, that allows you to send DTMF codes� You can connect an earphone (user supplied) to the earphone jack� NOTE: When the HM-245T is attached to the transceiver, audio is output from the HM-245T’s speaker� Belt clip Microphone [Emer]...
  • Page 56 FOR YOUR REFERENCE Troubleshooting The following conditions are not due to a malfunction� Check before sending a request for repair� No power comes ON. • Loose connection of the battery pack� - Clean the battery pack terminals� • The battery is exhausted� - Charge the battery pack�...
  • Page 57 FOR YOUR REFERENCE Troubleshooting The charging indicator blinks orange, or alternately blinks orange and green. • The battery pack is not properly inserted� - Properly insert the battery pack� (p� 7-6) • Charging the battery pack outside of the chargeable temperature range� - Charge the battery pack in the chargeable temperature range (0˚C to 60˚C (32˚F to 140˚F))�...
  • Page 58 FOR YOUR REFERENCE About the licences MbedTLS Unless specifically indicated otherwise in a file, Mbed TLS files are provided under the Apache License 2�0, or the GNU General Public License v2�0 or later (SPDX-License-Identifier: Apache-2�0 OR GPL-2�0-or-later)� A copy of these licenses can be found in apache-2�0�txt and gpl-2�0�txt Apache License Version 2�0, January 2004 http://www�apache�org/licenses/...
  • Page 59 FOR YOUR REFERENCE About the licences 3� Grant of Patent License� Subject to the terms and conditions of this License, each Contributor hereby grants to You a perpetual, worldwide, non-exclusive, no-charge, royalty-free, irrevocable (except as stated in this section) patent license to make, have made, use, offer to sell, sell, import, and otherwise transfer the Work, where such license applies only to those patent claims licensable by such Contributor that are necessarily infringed by their Contribution(s) alone or by combination of their Contribution(s) with the Work to which such Contribution(s) was submitted�...
  • Page 60 FOR YOUR REFERENCE About the licences APPENDIX: How to apply the Apache License to your work. To apply the Apache License to your work, attach the following boilerplate notice, with the fields enclosed by brackets “[]” replaced with your own identifying information� (Don’t include the brackets!) The text should be enclosed in the appropriate comment syntax for the file format�...
  • Page 61 FOR YOUR REFERENCE About the licences GNU GENERAL PUBLIC LICENSE Version 2, June 1991 Copyright (C) 1989, 1991 Free Software Foundation, Inc�,51 Franklin Street, Fifth Floor, Boston, MA 02110-1301 Everyone is permitted to copy and distribute verbatim copies of this license document, but changing it is not allowed�...
  • Page 62 FOR YOUR REFERENCE About the licences GNU GENERAL PUBLIC LICENSE TERMS AND CONDITIONS FOR COPYING, DISTRIBUTION AND MODIFICATION 0� This License applies to any program or other work which contains a notice placed by the copyright holder saying it may be distributed under the terms of this General Public License� The “Program”, below, refers to any such program or work, and a “work based on the Program”...
  • Page 63 FOR YOUR REFERENCE About the licences 3� You may copy and distribute the Program (or a work based on it, under Section 2) in object code or executable form under the terms of Sections 1 and 2 above provided that you also do one of the following: a) Accompany it with the complete corresponding machine-readable source code, which must be distributed under the terms of Sections 1 and 2 above on a medium customarily used for software interchange;...
  • Page 64 FOR YOUR REFERENCE About the licences 7� If, as a consequence of a court judgment or allegation of patent infringement or for any other reason (not limited to patent issues), conditions are imposed on you (whether by court order, agreement or otherwise) that contradict the conditions of this License, they do not excuse you from the conditions of this License�...
  • Page 65 FOR YOUR REFERENCE About the licences NO WARRANTY 11� BECAUSE THE PROGRAM IS LICENSED FREE OF CHARGE, THERE IS NO WARRANTY FOR THE PROGRAM, TO THE EXTENT PERMITTED BY APPLICABLE LAW� EXCEPT WHEN OTHERWISE STATED IN WRITING THE COPYRIGHT HOLDERS AND/OR OTHER PARTIES PROVIDE THE PROGRAM “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE�...
  • Page 66 FOR YOUR REFERENCE About the licences Gnomovision version 69, Copyright (C) year name of author Gnomovision comes with ABSOLUTELY NO WARRANTY; for details type `show w’� This is free software, and you are welcome to redistribute it under certain conditions; type `show c’ for details� The hypothetical commands `show w’...
  • Page 67 How the World Communicates A7605-13EX-2 1-1-32 Kamiminami, Hirano-ku, Osaka 547-0003, Japan © 2024–2025 Icom Inc. Mar. 2025...
