Normal Position - iwc PILOT’S WATCH CHRONOGRAPH SPITFIRE Operating Instructions Manual

1 Hour hand
8
2 Minute hand
3 Small seconds hand
4 Date display
5 Day display
6 Chronograph seconds hand
7 Minute counter
8 Hour counter
9 Screw-in crown
10 Start/stop push­button
11 Reset push­button
PILOT'S WATCH CHRONOGR APH SPITFIRE
— 8 —
7
1
6
2
X

Normal position

(screwed in)
10
0 Winding position
1 Date and day setting
5
2 Time setting
9
4
This watch has a screw­in crown. Screwing the crown into its
11 normal position (X) prevents the inadvertent adjustment of the
time or date and also acts as a double seal to prevent water
from seeping into the case. To release the crown, unscrew it
3
by turning it to the left, where it automatically assumes pos­
— 9 —
FUNCTIONS OF THE CROWN
NORMAL POSITION
PILOT'S WATCH CHRONOGR APH SPITFIRE
X 0 1 2
