Slide the workstation all the way back, and then lift to unmount.
6.

Disassembling the Workstation

To disassemble the unit to access the system board and peripheral components:
Remove the IO panel cover, and then remove all cables from the I/O panel,
1.
including the DC power cable.
Place a towel or soft cloth over your work surface to protect the touchscreen, and
2.
then place the workstation face-down on the surface.
Loosen the captive security screws using a hex key.
3.
Caution: The workstation's Power Supply Unit (PSU) contains a permanently-
connected fuse in the neutral line. After a fuse operation, parts of the PSU
remain energized and present a shock hazard as long as the AC power cord is
connected. Always disconnect the AC power cord before opening the unit for
service or configuration.
Chapter 12
Disassembling the Workstation
12-3
