Assembling the Battery Enclosure

The Enclosure for Battery (optional) enables select Oracle MICROS workstations to
operate using battery power.
Watch the video
Initial setup:
Remove the enclosure cover by unscrewing the two captive screws using the hex
1.
wrench included with your workstation.
Figure 4-1
Insert the battery into the enclosure by carefully aligning the battery power
2.
contacts (1) with the battery terminals. Gently press down on the battery to secure
the connection.
Figure 4-2
Replace the enclosure cover, and then tighten the two captive screws.
3.
The Enclosure for Battery
Inserting the Battery in the Enclosure for Battery
Chapter 4
Assembling the Battery Enclosure
4-11
