Note:
Oracle MICROS offers the Workstation 625/655 in multiple hardware
configurations. Depending on the model, your workstation may not include
some of the features described in this document.
Figure 2-1
Table 2-1
Feature
1. Magnetic Stripe Reader
2. Power Button
3. Audio expansion bar (optional)
4. Fingerprint Reader (optional)
5. Storage Expansion (optional)
6. Magnetic Stripe Reader (rear view)
7. Input/Output Panel (located behind I/O Panel Cover). See
information.

Primary I/O Ports

The Oracle MICROS Workstation 625 and Workstation 655 include an array of ports
for a variety of connectivity options. Note that port availability varies by model.
Oracle MICROS Workstation 625/655 Basic Features
Oracle MICROS Workstation 625/655 Basic Features
Chapter 2
Primary I/O Ports
Primary I/O Ports for more
