Fault
4. The pump runs but
gives no water.

9. Technical data

9.1 Storage temperature

Down to -30 °C.

9.2 Operating conditions

Minimum liquid
0 °C
temperature
Max. liquid temperature:
+55 °C, continuously.
For Unilift AP 12, AP 35 and
AP 50 without float switch,
Maximum liquid
where the media cannot
temperature
touch the cable and the
plug: up to + 70 °C every
30 min. for time periods
below 3 min.
Maximum 10 m below liquid
Installation depth
level
pH value 4-10
Density Maximum 1100 kg/m
Viscosity Maximum 10 mm
Max. spherical diameter:
Unilift AP12: 12 mm
Maximum particle
size
Unilift AP35: 35 mm
Unilift AP50: 50 mm
Technical data See the pump nameplate.
Always have at least 3 m free cable above
liquid level. This limits the installation
depth to 7 m for pumps with 10 m cable
and to 2 m for pumps with 5 m cable.

9.3 Sound pressure level

The sound pressure level of the pump is lower than
the limiting values stated in the EC Council Directive
2006/42/EC relating to machinery.
Cause
a) The pump is blocked by impurities.
b) The outlet pipe or valve is blocked by
impurities.
c) The impeller is not properly fixed to the
shaft.
d) There is air in the pump.
e) The liquid level is too low. The inlet
strainer is not completely submerged in
the pumped liquid.
f) Pumps with float switch: The float switch
does not move freely.
3
2
/s
Remedy
Clean the pump.
Clean the outlet pipe or valve.
Tighten the impeller.
Vent the pump and the outlet
pipe.
Submerge the pump in the liquid
or adjust the level switch.
Adjust the float switch. See
section
switch cable

10. Disposing of the product

This product or parts of it must be disposed of in an
environmentally sound way:
1. Use the public or private waste collection service.
2. If this is not possible, contact the nearest
Grundfos company or service workshop.
The crossed-out wheelie bin symbol on
a product means that it must be
disposed of separately from household
waste. When a product marked with this
symbol reaches its end of life, take it to a
collection point designated by the local
waste disposal authorities. The separate collection
and recycling of such products will help protect the
environment and human health.
See also end-of-life information at
www.grundfos.com/product-recycling.
3.2.5 Adjusting the float
length.
