N007 G98 Y-750.0 ;
N008 G99 X1200.0 ;
N009 Y-550.0 ;
plane
N010 G98 Y-350.0 ;
N011 G00 X0 Y0 M5 ;
N012 G49 Z250.0 T15 M6 ;
N013 G43 Z0 H15 ;
N014 S20 M3 ; spindle starts
N015 G99 G82 X550.0 Y-450.0 ;
Z-130.0 R-97.0 P30 F70;
N016 G98 Y-650.0 ;
N017 G99 X1050.0 ;
N018 G98 Y-450.0 ;
N019 G00 X0 Y0 M5 ;
N020 G49 Z250.0 T31 M6 ;
N021 G43 Z0 H31 ;
N022 S10 M3 ; spindle starts
N023 G85 G99 X800.0 Y-350.0 ;
Z-153.0 R47.0 F50 ;
N024 G91 Y-200.0 ;
Y-200.0 ;
N025 G00 G90 X0 Y0 M5 ; return to reference point, spindle stops
N026 G49 Z0 ;
N027 M30 ;%
2.5 Conversion of G command

2.5.1. Program coordinates rotation G68 and G69

Format:
(1)Coordinate rotation function starts
G68 G17 X_ Y_ R_; Coordinate rotation starts
G68 : Coordinate rotation command
ADTECH9 Series CNC Programming Manual
process #3 hole after positioning, return to start point plane
process #4 hole after positioning, return to point R plane
process #5 hole after positioning, return to point R
process #6 hole after positioning, return to start point plane
return to reference point, spindle stops
cancel tool length compensation, change tool
start point plane, tool length compensation
process #7 hole after positioning, return to point R plane
process #8 hole after positioning, return to start point plane
process #9 hole after positioning, return to point R plane
process #10 hole after positioning, return to start point plane
return to reference point, spindle stops
cancel tool length compensation, change tool
start point plane, tool length compensation
process #11 hole after positioning, return to point R plane
process #12, #13 holes after positioning, return to point R plane
cancel tool length compensation
program stops
