Example of user-defined alarm configuration: the range of the sequence
number is 200~215, the range of corresponding external alarm sequence
number is 1~16, sequence number corresponds to bit number 1~16 of external
alarm register, and the later alarm prompt is the content generated by the alarm
of current number. No sequence number can be repeated.
ADTECH9 Series CNC Programming Manual
Example of user macro configuration: the range of
sequence number is 17~100 and the range of
corresponding macro address is 500~999; this macro
address is nonvolatile. The user can customize up to 50
addresses.
