Adtech ADTECH9 Series Programming Manual page 26

S/N Data content
1 Plane selection
2 Arc direction
End
3
point
Distance from start
point to circle center
4
Arc radius
5 Feeding rate
Details:
G02 (G03) is modal instruction.
The arc crossing multiple quadrants can be specified in one program segment.
Note:
Arc direction
X-Y plane: look to negative direction from Z axis
X-Z plane: look to negative direction from Y axis
Y-Z plane: look to negative direction from X axis
ADTECH9 Series CNC Programming Manual
Arc Interpolation Command Format Description
Instruction
Plane selection
Arc direction
Two axes instruction in
G90 mode
X, Y, Z
Two axes instruction in
G91 mode
X, Y, Z
Distance from start point
to circle center
Arc radius
Feeding rate
Meaning
Specify the arc interpolation on X-Y
plane
Specify the arc interpolation on Z-X
plane
Specify the arc interpolation on Y-Z
plane
Arc interpolation in clockwise direction
CW
Arc interpolation in counterclockwise
direction CCW
The coordinate value of the end point
position in current
coordinate system
Distance from start point to end point
(directional)
Two axes instruction in I, J, K
Arc radius
The speed of arc motion
workpiece
