Adtech ADTECH9 Series Programming Manual page 68

G84
G85
G86
G87
G88
G89
Format:
After G73/G74/G76/G81~G89, give hole processing parameters,
The format follows: (See table 10.2 for details)
G××X_ Y_ Z_ R_ Q_ P_ F_ K_ ;
G××
X_ Y_ Z_
R_ Q_ P_ F_
K_
Details:
Generally, one hole processing fixed cycle completes the following six steps:
G73/G74/G76/G81~G89,
1. X, Y axis quick positioning. 2. Z axis quickly positions to point R. 3. Hole
processing. 4. Hole bottom action. 5. Z axis returns to point R. 6. Z axis
quickly returns to the start point.
ADTECH9 Series CNC Programming Manual
Pause –
Cutting feeding
spindle CCW
－
Cutting feeding
Cutting feeding Spindle stop
Cutting feeding Spindle CW
Pause- spindle
Cutting feeding
stop
Cutting feeding Pause
: hole processing method
: position parameters of hole processed
: hole processing parameters
: repeat times
Right thread
Cutting feeding
taping
Cutting feeding Boring cycle
Rapid traverse Boring cycle
Rapid traverse Boring cycle
Manual Boring cycle
Cutting feeding Boring cycle
