Benchmark Games Ticket Station Manual page 46

C13: Hall Effect Sensor Micro F
Pin 1 Power 5V Red
Pin 2 Signal Blue/Gry
Pin 3 Ground Black
C14: Ticket Scanner 1/2 Micro F
Pin 1 12V Power Yellow
Pin 2 Ticket Scanner 2 Green/Wht
Pin 3 Ticket Scanner 1 Green/Blk
Pin 4 Ground Black
C15: Ticket Scanner 3/4 Micro F
Pin 1 12V Power Yellow
Pin 2 Ticket Scanner 4 Green/Org
Pin 3 Ticket Scanner 3 Green/Red
Pin 4 Ground Black
C16: Opto Transmitter Micro F
Pin 1 Ground Black
Pin 2
Pin 3 12V Power Yellow
C17: Opto Transmitter Micro F
Pin 1 Ground Black
Pin 2
Pin 3 12V Power Yellow
C18: Ticket Count Optic Micro F
Pin 1 Ground Black
Pin 2 Signal Purple/Blk
Pin 3 12V Power Yellow
C19: Ticket Insert Optic Micro F
(Motor)
Pin 1 Ground Black
Pin 2 Signal Blue/Blk
Pin 3 12V Power Yellow
C20: Speaker
C2:P7
C2:P5
C2:P6 C15:P4 C14:P4
C1:P8 C19:P3 C18:P3
C2:P1
C2:P2
C2:P6 C15:P4 C13:P3
C1:P8 C19:P3 C18:P3
C2:P6 C14:P4 C13:P3
C1:P3 C19:P1 C18:P1
C1:P8 C19:P3 C18:P3
C1:P3 C19:P1 C18:P1
C1:P8 C19:P3 C18:P3
C1:P3 C19:P1 C16:P1
C2:P11
C1:P8 C19:P3 C14:P1
C1:P3 C18:P1 C16:P1
C2:P12
C1:P8 C18:P3 C14:P1
C15:P1 C16:P3 C17:P3
C14:P1 C16:P3 C17:P3
C17:P1 C11:P1 C5:P3
C14:P1 C15:P1 C17:P3
C16:P1 C11:P1 C5:P3
C14:P1 C15:P1 C16:P3
C17:P1 C11:P1 C5:P3
C15:P1 C16:P3 C17:P3
C17:P1 C11:P1 C5:P3
C15:P1 C16:P3 C17:P3
C9:P1 C5:P4 C7:P4
C9:P1 C5:P4 C7:P4
C7:P3
C9:P1 C5:P4 C7:P4
C7:P3
C9:P1 C5:P4 C7:P4
C7:P3
C9:P1 C5:P4 C7:P4
C7:P3
C9:P1 C5:P4 C7:P4
