Benchmark Games Ticket Station Manual page 43

Connector/ Device/ Signal
Pin
C1: Door to Main HNS
connector
Pin 1 Printer GND
Pin 2 Main Controller
GND
Pin 3 Ground
Pin 4 RS 485 B
Pin 5 RGB Sync Input
Pin 6 Printer Power 12V
Pin 7 Main Controller
Power 12V
Pin 8 12V Power
Pin 9 RS 485 A
Pin 10 RGB Sync Output
C2: Main Controller
Board (P5) Input
Pin 1 Ticket Scanner 2
Pin 2 Ticket Scanner 1
Pin 3
Pin 4 RGB Sync Input
Pin 5 Hall Effect Sensor
Pin 6 Ticket Reader GND
Pin 7 Hall Effect Sensor
Power 5V
Pin 8 Main Controller
GND
Pin 9 Main Controller
Power 12V
Type/ To/ To/
Color From From
Mini F
Black C6:P2
Black C2:P8
Black C19:P1 C18:P1
Gray C4:P1 C5:P2
Blue/Org C2:P4
Yellow C6:P1
Yellow C2:P9
Yellow C19:P3 C18:P3
Blue C4:P2 C5:P1
Blue/Red C3:Pp
Mini F
Green/Wht C14:P2
Green/Blk C14:P3
Blue/Org C1:P5
Blue/Gry C13:P2
Black C15:P4 C14:P4
Yellow C13:P1
Black C1:P2
Yellow C1:P7
To/ To/ To/
From From From
C16:P1 C17:P1 C11:P1
C7:P2
C14:P1 C15:P1 C16:P3
C7:P1
C13:P3
To/ To/ To/
From From From
C5:P3 C7:P3
C17:P3 C9:P1 C5:P4
Comments
Is a twisted Pair with
Pin 9
C7:P4
Is a twisted Pair with
Pin 4
