Benchmark Games Ticket Station Manual page 45

Pin 1 RS 485 A Blue
Pin 2 RS 485 B Gray
Pin 3 Ground Black
Pin 4 12 V Power Yellow
C6: Printer Power
Pin 1 12V Power Yelow
Pin 2 Ground Black
Pin 3
Pin 4
C7: 5 Didit Display Micro F
Pin 1 RS 485 A Blue
Pin 2 RS 485 B Gray
Pin 3 Ground Black
Pin 4 12V Power Yellow
C8: Stepper Motor Micro F
Pin 1 Stepper Green White/Grn
Pin 2 Stepper Blue White/Blu
Pin 3 Stepper Black White/Blk
Pin 4 Stepper Red White/Red
C9: Button Power
Pin 1 12 V Power Yellow
C10: Button LED
Pin 1 Signal Black/Wht
C11: Button Ground
Pin 1 Ground Black
C12: Button Switch
Pin 1 Switch Signal Purple/Wh
t
C1:P4 C4:P2 C7:P1
C1:P9 C4:P1 C7:P2
C1:P3 C19:P1 C18:P1
C1:P8 C19:P3 C18:P3
C1:P6
C1:P1
C1:P4 C4:P2 C5:P1
C1:P9 C4:P1 C5:P2
C1:P3 C19:P1 C18:P1
C1:P8 C19:P3 C18:P3
C3:P10
C3:P9
C3:P2
C3:P1
C1:P8 C19:P3 C18:P3
C3:P5
C1:P3 C19:P1 C18:P1
C2:P10
C16:P1 C17:P1 C11:P1
C14:P1 C15:P1 C16:P3
C16:P1 C17:P1 C11:P1
C14:P1 C15:P1 C16:P3
C15:P1 C16:P3
C16:P1 C17:P1 C5:P3
Is a twisted Pair with
Pin 2
Is a twisted Pair with
Pin 1
C7:P3
C17:P3 C9:P1 C7:P4
Is a twisted Pair with
Pin 2
Is a twisted Pair with
Pin 1
C5:P3
C17:P3 C9:P1 C5:P4
C17:P3 C5:P4 C7:P4
C7:P3
