General

3 General
3.1

Authorized use

•
The device is exclusively applicable for lifting, transporting and laying of dense stone slabs, concrete elements and
steps kerb stones and so on with the corresponding suction plates.
•
This device can be hung from any carrier/support frame (e.g. excavator) by means of load hook, chains, cables and
such like.
•
Various suction plates can be fitted to the device (SH-1000-MINI-H) via a quick release locating pin, enabling it to
be used for many different purposes and with many different loads.
•
The carrying capacity of the device of 1000kg must not be exceeded!
This device is equipped with the following safety
devices:
Requirements for hydraulic operation (operating
hydraulics of the carrier):
•
The device is only designed for the use specified in this documentation.
•
Every other use is not authorized and is forbidden!
•
All relevant safety regulations, corresponding legal regulations, especially regulations of the
declaration of conformity, and additional local health and safety regulations have to be observed.
ATTENTION: The use of this device is only permitted in proximity to the ground (→ chapter "Safety at
work").
5240.0020
• Safety vacuum storage tank (vacuum tank volume 12,5 l).
•
Vacuum gauge.
•
Pressure relieve valve.
•
Acoustic warning device.
•
Volumetric flow (l/min), usable min. 16, max. 80
•
Working pressure (bar), usable min. 80, max. 320
•
Backflow pressure: max. 10 bar
•
Lockable control lever for operating hydraulics (continuous oil
flow)
V4
