Safety
2.3

Function Control

•
Before using the device check the functions and the working condition.
•
Maintenance and lubrication are only permitted when device is shut down!
●
Do not use the device, until all faults which can cause safety hazards are removed.
●
If there are any cracks, splits or damaged parts on any parts of the device, immediately stop using it.
•
The operating instructions must be available at the workplace every time.
•
Do not remove the data-plates of the machine.
●
Unrecognisable information signs must be replaced.
2.3.1

Safety at work

•
The use of the vacuum lifting device is only permitted in proximity to the ground.
The suctioned load must be lowered immediately after picking up (e.g. from a pallet or a truck) to just
above the ground (approx. 20 - 30 cm).
The load must then be secured by the load securing chain and may only then be transported to the
installation site. To transport the load, lift it only as high as necessary (recommended approx. 0.5 m
above the ground).Do not swing it over peoples heads. Danger to life!
•
The manual guiding of is only allowed for devices with handles.
•
The operator is not allowed to leave the control unit as long as the vacuum lifting device loaded with
load (stone slab). The load must always be in the range of vision of the operator.
•
Always keep an eye on the vacuum gauge. Never lift loads when the vacuum is below the required
under pressure (mbar). If the pointer of the pressure gauge moves into the red danger zone, lower
the load immediately! Danger! Load could fall down!
•
While using the vacuum lifting device is the stay of persons in the working area forbidden. Except it is
indispensable. Caused of the way of using the vacuum lifting device , e.g. if the device must be leaded by
hand (on the handles).
•
While using the vacuum lifting device be sure that there are no persons in the working area. Danger to
Life!!
•
The device must never be subjected to a force acting in a lateral direction due to diagonal pulling.
•
Do not lift any components off-centre, because that could fall down. Danger of tilting!
•
Release the load only when it is completely safely resting on the surface. Keep fingers away from the
load when you release it as they can be crushed!
•
The capacity and the nominal width the vacuum lifting device are not allowed to cross over.
•
Do not use the vacuum lifting device to jerk seized set down load.
•
Jerking up or down of the unit with or without load is prohibited! Unnecessary vibrations must be
avoided. As well as fast driving with the carrier/ hoist over uneven terrain! Danger to life/accident:
The load could fall or the load handling attachment could be damaged! As a general rule, only drive
at walking speed with the lifted load!
