Installation

4.2

Positioning of suction plates

For each application of the device (SH-1000-MINI-H) the different suction plates must be fastened to the

corresponding place to the device.

The device (SH-1000-MINI-H) with sucked in load (stone slab) must always hang on the support frame

(e.g. excavator) vertical.

Suspension lug for crane hook

on support frame with laying

kerb stones

Suction plate support

for kerb stones

5240.0020

Suspension lug for crane hook on

support frame with laying stone

slabs, concrete elements and steps

and so on.

Suction plate support for stone

slabs, concrete elements and

steps

18 / 34
