Underside panel
Fig. 4:
The following table contains details on the underside panel's significant elements.
Underside panel elements table
Item
A
B
C

3.1.5 Top Panel (LEDs)

The LED panel provides information on the state of the components (whether they are active or not) and on network
activity.
LED Panel
Fig. 5:
Teldat 4Ge Router
Description
Slots for wall mounting.
Rubber feet.
Perforations to install a DIN rail mount. (Optional.)
3 Components and Power Supply
7
