Technical Information
A.4.2 LAN Interface
PROTOCOLS
PORTS
SPEED
CONNECTOR
A.4.3 Wireless WAN Interface
STANDARDS
SPEED
CONNECTOR
ANTENNA
A.4.4 Power Supply
INPUT VOLTAGE
INPUT CURRENT
JACK
INTERNAL PIN
A.4.5 External Power Supply
INPUT VOLTAGE
INPUT CURRENT
INPUT FREQUENCY
A.4.6 Dimensions and weight
TYPE
LENGTH x WIDTH x HEIGHT
WEIGHT
26
Ethernet (802.3).
Port managed with MDI/MDX autodetection.
10/100/1000 Mbps (BaseT).
RJ45 female.
GPRS, UMTS, HSDPA, HSUPA, HSPA+, LTE ... Depends on the router's Wire-
less WAN interface version.
Depends on the router's Wireless WAN interface version. Please check the mod-
ule manual.
Up to 3 RF SMA female.
Depends on the type of Wireless WAN module. Please check the antenna catalog
for cellular interfaces.
+12 V DC.
1200 mA.
5.5 mm.
2.5 mm.
100-240 V AC.
1.0 A.
50-60 Hz.
Desktop or wall-mounted.
145 x 160 x 50 mm.
0.3 kg.
