Chapter 3 Components and Power Supply
The following chapter provides detailed information on the Teldat 4Ge router chassis and its components. This in-
formation includes:

• Components.

• Information on assembly.
• Power supply.
• RESET button.
• Data connection.
• SIM card installation.
3.1 Components

3.1.1 Front Panel

The following figure shows the front panel. Here you can see where to insert one of the WWAN antenna connectors
and the SIM card slot.
Front Panel
Fig. 1:
The front panel elements are as follows:
Front panel elements table
Item
A
B

3.1.2 Rear Panel

The following figure shows the rear panel. Here you can see all the Teldat 4Ge connectors.
Teldat 4Ge Router
Description
WWAN antenna for the Teldat 4Ge.
SIM card slot.
