3 Components and Power Supply

Chapter 3 Components and Power Supply
The following chapter provides detailed information on the chassis of the Teldat Connect-4GE router and its compon-
ents. This information includes:

• Components.

• Information on assembly.
• Power supply.
• RESET button.
• Data connection.
• SIM card installation.
3.1 Components

3.1.1 Front Panel

Figure 1 shows the front panel. Here you can find one of the WWAN antenna connectors and the slot for SIM card in-
sertion.
Fig. 1: Front Panel
The front panel elements are as follows:
FRONT PANEL ELEMENTS Table
Item
A
B

3.1.2 Rear Panel

Figure 2 shows the rear panel. Here you can find other Teldat Connect-4GE connectors.
Fig. 2: Rear panel
4
Description
WWAN antenna connector.
Slot for the SIM card.
