Teledyne Meridian User Manual page 9

Table of Contents (Continued)
Sect. # Section Title
7.1. Calibrating the Device
7.1.1. Calibration Hookup
7.2. Calibration Methods
7.2.1. Zero Calibration
7.2.2. Span Calibration
7.3. Maintaining the Device
7.3.1. Replacing a Sensor
7.3.2. Changing the E-Chem Sensor's Range
7.3.3. Selecting the Combustible IR Sensor's Target Gas
7.3.4. Replacing the Intrinsically Safe (IS) Barrier PCB
7.3.5. Replacing the Power Supply PCB (3 or 4-Wire)
7.3.6. Replacing the Power Supply PCB (2-Wire)
7.3.7. Trimming the 4-20mA Loop
7.3.8. Replacing the LCD PCB/CPU PCB
7.3.9. Replacing the Terminal/Relay/MODBUS RS-485 PCB
7.3.10. Replacing the Meridian NPT Ex Seal
7.3.1 1. Replacing the Meridian Detector Body Assembly
7.3.12. Re-mapping the Sensors
7.3.13. Clearing a Sensor Fault
7.4. Troubleshooting the Device
A. Specifications
A.1. Device Specifications
A.2. Combustible (LEL), IR, Cat-bead Sensor Specifications
A.3. Toxic (E-Chem) Sensor Specifications
B. Gas Sensor Information
B.1. Sensor Technology Overview
B.2. Sensor Performance Factors
B.3. Combustible Cat-Bead Sensor K-Factors
