5.1.2 Using the Information Menu

Use the magnetic keys to navigate through the menu structure as necessary. See
Structure. The parameters are detailed in
MAIN MENU
INFORMATION
>
SETUP
>
CALIBRATION
>
DATALOG
>
DISPLAY
>
USER ACCESS
>
Information contained herein is classified as EAR99 under the U.S. Export Administration Regulations. Export, reexport or diversion contrary to U.S. law is
Table 5-1: Information Menu
INFORMATION
MERIDIAN INFO
>
CEC X INFO
>
SENSOR X INFO
>
Figure 5-3: Information Menu Structure
USE AND DISCLOSURE OF DATA
prohibited.
Figure 5-3: Information Menu
Parameters.
MERIDIAN INFO
NAME
: TankRm#A12
SN
: XFRE1235
MODEL
: 511CL
UPTIME : 271171
REV
: 1.0.4
CEC X INFO
TYPE
: NOT INSTALL
HW/FW :
TX/CEC : XXXXh
STATUS : XXXXXXXXh
TX
: XXXXXXXXXX
RX
: XXXXXXXXXX
SENSOR X INFO
>
GENERAL
>
LIVE
>
CAL DATES
>
CAL INFO
MERIDIAN
UNIVERSAL GAS DETECTOR
CONFIGURATION & SETUP
SENSOR X GEN
SN
: 115Ayyww
GAS TYP : H2S
GAS UNT : PPM
MODEL # : ECHEM
TYPE
:1
REV
1.13
SENSOR X LIVE
GASCONC : 0.0
VOLTS
: 2.758
TEMP(C)
: 19.1
GAS A/D
: 20
UPTIME
: 270555
SENSOR X DATES
MFG DATE
: 00/00/00
INST DATE
: 00/00/00
PRI DATE
: 00/00/00
CUR DATE
: 00/00/00
CAL TIME
: 16:21
SENSOR X CAL
CAL FACTOR : 0.000
CAL TEMP
: 22
ZERO
:21
SEN LIFE
:100%
CAL REQD
: YES
5-5
