Teledyne Meridian User Manual page 151

Table 5-16: MODBUS Registers - Sensor X Data (Continued)
InstallCalTemperature
40539 21A R Cal temperatures
xx.x°C
PriorCalTemperature
40541 21C R Cal temperatures
xx.x°C
Alarm1Setpoint
40543 21E R/W Alarm set/reset points
xx.x (defaults to a 10% of FS)
Alarm1ResetPoint
40545 220 R/W Alarm set/reset points
xx.x (defaults to a 9% of FS)
Alarm2Setpoint
40547 222 R/W Alarm set/reset points
xx.x (defaults to a 25% of FS)
Alarm2ResetPoint
40549 224 R/W Alarm set/reset points
xx.x (defaults to a 22% of FS)
Alarm3Setpoint
40551 226 R/W Alarm set/reset points
xx.x (defaults to a 50% of FS)
Alarm3ResetPoint
40553 228 R/W Alarm set/reset points
xx.x (defaults to a 45% of FS)
NegativeFaultSetpoint
40555 22A R/W
x.x % (5% is max)
Deadband
40557 22C R/W
x.x % (5% is max)
Information contained herein is classified as EAR99 under the U.S. Export Administration Regulations. Export, reexport or diversion contrary to U.S. law is
USE AND DISCLOSURE OF DATA
prohibited.
MERIDIAN
UNIVERSAL GAS DETECTOR
CONFIGURATION & SETUP
FP32 4
FP32 4
Sensor
FP32 4
Setup
Sensor
FP32 4
Setup
Sensor
FP32 4
Setup
Sensor
FP32 4
Setup
Sensor
FP32 4
Setup
Sensor
FP32 4
Setup
FP32 4
Sensor
FP32 4
Setup
5-51
