AC Output Data (ON-Grid )
Datasheet
Nominal AC power
Max. AC power
output to utility grid
Max. AC power from
utility grid
Max. AC current
output to utility grid
Max. AC Current
from utility grid
Nominal grid voltage
Grid voltage range
Nominal grid freqency
Grid freqency range
Output power factor
Output THDi
(@Nominal output)
HYD 10-20KTL-3PH
HYD
10KTL-3PH
10000W
11000VA
20000VA
16A
29A
3/N/PE, 220/380Vac, 230/400Vac
45Hz~55Hz/55Hz~65Hz
~ 1(0.8 leading to 0.8 lagging )
- 61 -
Copyright © Shenzhen SOFARSOLAR Co., Ltd
HYD
15KTL-3PH
15000W
16500VA
30000VA
24A
44A
184Vac~276Vac
50Hz/60Hz
<3%
User manual
HYD
20KTL-3PH
20000W
22000VA
40000VA
32A
58A
