*5.Set battery parameters (Take the default input channel configuration as an
example).Start with battery 1 and work your way up to battery n.
Battery Type
Table 6-2 Default values for other Settings
Energy Storage Mode
IV Curve Scan

6.3. Menu

Fig 6-1. Main interface
HYD 10-20KTL-3PH
Type of band
communication protocol
1.Battery Address
2.Battery Charge Current
Limit
3.Battery Discharge
Current Limit
4.Battery DOD(EOD)
Item
EPS Mode
Anti Reflux
DRMs
Copyright © Shenzhen SOFARSOLAR Co., Ltd
Lead acid or no protocol
type
1.Battery Capacity
2.Battery Nominal Voltage
3.Battery Cell Type
4.Battery Charge Current
Limit
5.Battery Discharge Current
Limit
6.Battery DOD(EOD)
The default state
Self-use mode
Disable
Disable
Disable
Disable
- 34 -
