Sofar solar HYD 10K-20KTL-3PH User Manual page 16

10
11
12
13
14
15
16
17
18
19
20
21
HYD 10-20KTL-3PH
Metal terminals secured
to BAT+ input power
cables
M6 Hexagon screws
M8*80 Expansion bolts used
to secure the wall-mount
bracket to the wall
AC Grid connector
AC Output connector
Link port 4pin connector
DRMs connector
CT 6pin connector
COM 8pin connector
Manual
The warranty card
Registration Form
- 11 -
Copyright © Shenzhen SOFARSOLAR Co., Ltd
User manual
2pcs
2pcs
4pcs
1pcs
1pcs
2pcs
1pcs
1pcs
1pcs
1pcs
1pcs
1pcs
