3.7. Moving the HYD 10-20KTL-3PH

Step 1 Open the packaging, insert hands into the slots on both sides of the
inverter and hold the handles, as shown in Fig.3-4.
Fig. 3-4 Moving the inverter
Step 2 Lift the inverter from the packing case and move it to the installation
position.
moving the inverter because the inverter is heavy.
floor because the power ports and signal ports are not designed to
support the weight of the inverter. Place the inverter horizontally.
Attention
inverter to protect its shell.

3.8. Installing HYD 10-20KTL-3PH

Step 1 Determine the positions for drilling holes, ensure the hole positions
are level, then mark the hole positions using a marker pen, use the hammer drill to
HYD 10-20KTL-3PH
To prevent device damage and personal injury, keep balance when
Do not put the inverter with its wiring terminals contacting the
When placing the inverter on the floor, put foam or paper under the
