3.3. Product Overview

HYD 10-20KTL-3PH inverter is 100% strictly inspected before package and
delivery. It is forbidden to put the HYD 10-20KTL-3PH inverter upside down
during delivery.
installation.
Fig.3-2 HYD 10-20KTL-3PH inverter overview
Table 3-2 HYD 10-20KTL-3PH inverter overview
1
Battery input terminals
2
DC switch
3
PV input terminals
4
Load connection port
5
Grid connection port
6
USB/WiFi

3.4. Tools

Prepare tools required for installation and electrical connections.
Table 3-3 Tools required for installation and electrical connections.
NO.
Tool
1
HYD 10-20KTL-3PH
Please check the product package and fittings carefully before
Model
Hammer drill
Recommend
dia. 6mm
Copyright © Shenzhen SOFARSOLAR Co., Ltd
CAUTION
7
DRMs
8
COM
9
Link Port 1
10
Link Port 0
11
CT
12
LCD
drill
Used to drill holes on the wall.
- 12 -
User manual
Function
