Glossary

CHG Power = battery charging power, default charging power is
50W.
Temp Unit = temperature unit, Celsius or Fahrenheit is selectable.
Safe Temp = safe temperature.
Input Low = input voltage is low.
CHG I = battery charging current.
DISC I = battery discharging current.
Cap = capacity or cutoff protection capacity.
Cut Temp = cutoff temperature.
D&C cycles = discharge/charge cycles or charge/discharge cycles.
DISC V = discharge voltage.
-dV = delta voltage for NiMH/NiCd battery.
Batt Preset = battery information setting, such as battery type, cells,
current etc.
Cut Time = protection cutoff time.
· 10
Charging Program
Depends on different battery type, the operation programs are different.
Batt
Operation
Type Program
Balance
Charge
Fast
Charge
LiPo
LiHV
Lilon Charge
LiFe
Non Bal
Discharge
Storage
Charge
Discharge
NiMH
NiCd
D&C Cycle
Re-Peak
(NiMH only)
Charge
Pb/
Pb AGM
Discharge
B6 Evo B6 Evo

Program Descriptions

Description
Charge the battery and balance the battery cell
voltage during charging
Charge the battery and speed up on balancing.
Charge the battery without the balance lead connected
Discharge the battery to certain voltage level
Charge or discharge the battery to a certain voltage level
for storage
Charge the battery to the expected voltage
Discharge the battery to a certain voltage level
Discharge -> Charge
Peak charge the battery once, twice or three
times in cycle automatically.
Charge the battery to the expected voltage
Discharge the battery to the expected voltage
