Program 1-8

B6 Evo charger minimizes program and system settings to 10 only,
eight of which are preset for practical applications:
Battery No.: 1/10
2S LiPo for RC car/boat
LiPo 7.4V/2S
Battery No.: 2/10
3S LiPo for fixed wing/multirotor
LiPo 11.1V/3S
Battery No.: 3/10
4S LiPo for fixed wing/multirotor
LiPo 14.8V/4S
Battery No.: 4/10
6S LiPo for EDF/fixed wing
LiPo 22.2V/6S
Battery No.: 5/10
4S LiHV for racing drone
LiHV 14.8V/4S
Battery No.: 6/10
2S LiFe for radio and receiver
LiFe 6.6V/2S
Battery No.: 7/10
Commonly used program for any NiMH battery
NiMH AUTO
Battery No.: 8/10
Commonly used program for Pb battery
Pb 12.0V/6S
Please scan and watch the tutorial video for
operational instructions.
Video
Tutorial
· 12

Quick Start Guide

Do not overcharge nor over-discharge batteries.
Remove the battery and unplug the charging unit from the power
source when not in use.
Opening, disassembling, modifying, tampering with the unit may
invalidate its guarantee, check warranty terms.
Do not misuse in any way! Use for intended purpose and function
only.
Before charging, always connect the charging leads to the charger
first, then connect to the battery. After charging finishes, remove the
battery first.
As the first 8 programs are occupied and preset, below operation
instructions will be based on empty program, for example, program 9
or 10.
Lithium Battery Program
Battery No.: 9/10
None
START/ENTER
MODE:
Batt Preset
START/ENTER
BATT PRESET:
Type:
BATT PRESET:
Type:
INC
BATT PRESET:
Cells: 22.2V/6S
INC
B6 Evo B6 Evo
(LiPo/LiFe/Lilon/LiHV)
Click INC/DEC to select one empty program.
1/1
1/1
ENTER to get the value flash.
None
Click INC/DEC to select desired Lithium
1/6
battery type, for example, LiPo.
LiPo
ENTER to get the value flash, then click
2/6
INC/DEC to select correct Lithium battery cells.
ENTER to confirm.
