MECHANICAL SPECIFICATIONS

Range
Nominal Flow
Maximum Flow
Weight
Nominal Operating Pressure
Maximum Operating Pressure
Maximum Fog angle
Operating Temperatures
Materials used
3.3

USE WITH SALT WATER

Use with salt water is permissible provided the equipment is thoroughly cleaned with fresh water after each use. The service life of the
equipment may be shortened due to the effects of corrosion, and is not covered under warranty.
3.4

NOZZLE COUPLINGS

Master Foam nozzles in 250, 350, 500, 750, 1000, and 1250 gpm (950, 1325, 1900, 2900, and 4800 l/min) versions are available with a
2.5 inch coupling (NH, NPSH or BSP).
Master Foam nozzles in 1500 and 2000 gpm (5700 and 7600 l/min) versions have a 3.5" (NH) coupling as standard.
When tightening the coupling, make sure the foam inlet is pointing downward for ease of attaching the concentrate inlet hose.
CAUTION
CAUTION
3.5

ELECTRIC INSTALLATION

Nozzles with electric stream shaper actuation are shipped with a wiring diagram (TFT item #LIM-040). Other documentation is available
on request. ER nozzles are equipped with manual override in case of electrical power failure.
WARNING
4.0

OPERATION

4.1

PATTERN CONTROL

The Master Foam's spray pattern is adjustable from straight stream to a 90° wide fog.
On models with manual shapers turning the stream shaper clockwise (as seen from the operating position behind the nozzle) moves the
shaper to the straight stream position. Turning the shaper counterclockwise will result in an increasingly wider pattern. Only 90° of
rotation is required to go from wide fog to a straight stream.
On RC Master Foam nozzles, use the FOG and STRAIGHT STREAM buttons on the operator station to change the pattern.
Since the stream trim point varies with flow, the stream should be "trimmed" after establishing a steady flow. To properly trim the stream,
first open to a narrow fog. Then close the stream to parallel to give maximum reach.
WARNING
NOTICE
NOTICE
©Copyright Task Force Tips LLC 2015-2020
250 gpm 350 gpm
950 l/min 1325 l/min
306 gpm 428 gpm
1160 l/min 1620 l/min
Cast Aluminum, Aluminum 6000 series hard anodized MIL 8625 class 3 type 2, Stainless Steel 300
Mismatched or damaged waterway connections may cause equipment to leak or uncouple under
pressure. Failure could result in injury. Equipment must be mated to matched connections.
Dissimilar metals coupled together can cause galvanic corrosion that can result in the inability to
uncouple the connection, or complete loss of engagement over time. Failure could cause injury. Per
NFPA 1962, if dissimilar metals are left coupled together, an anti-corrosive lubricant should be
applied to the connection and the coupling should be disconnected and inspected at least
quarterly.
This device is not rated as ignition proof, explosion proof, or intrinsically safe. Use only in locations
with adequate ventilation and no hazard of flammable vapor buildup.
The nozzle reaction is greatest when the shaper is in the straight stream position. Sudden changes
in pattern can cause changes in reaction, leading to loss of footing or an out of control nozzle. The
nozzle operator must be prepared for a change in reaction as the pattern is changed.
Turning the shaper further forward will cause stream crossover and reduce the reach of the nozzle.
The widest pattern is useful for protection and cooling, but does not educt foam.
SMALL
500 gpm 750 gpm
1900 l/min 2900 l/min
612 gpm 918 gpm
2320 l/min 3475 l/min
7.3 lbs / 3.3 kg
100 psi / 690 kPa / 7bar
150 psi / 1034 kPa / 10.3bar
-40°F to 135°F
-40°C to 57°C
series, Nylon, Nitrile Rubber
8
MEDIUM
1000 gpm 1250 gpm
3800 l/min 4800 l/min
1224 gpm 1530 gpm
4630 l/min 5790 l/min
16.9 lbs / 7.7 kg
90°
LIZ-030 October 29, 2020 Rev13
