Room thermostat for fan-coils (auto version with actuator)
Table of Contents

Advertisement

User's manual

To start the thermostat after the same has
been installed, proceed as follows:
1. Select the Summer / Winter operation;
2. Select the operating mode;
3. Select the fan speed.

"Summer / Winter" selection

To switch from the "Winter" operation (i.e. heat-
ing system) to the "Summer" operation (i.e.
cooling system), and vice versa, press the 1+2
button combination. The selected operation
will be indicated on the display by the "Winter"
or "Summer" icons.
Winter
5
Summer
TOP
COVER
THERMOSTAT
FRONT
