The confi guration parameters are represented
by an index (P01, P02...) on the display and
by pressing buttons "1" and "2", the parameter
indexes will be scrolled through. Press button
"3" to enter the displayed parameter.
To modify the current parameter, press buttons
"1" and "2". To exit the parameter, press button
"3". Once all parameters have been set, press
button "1" until the "END" message appears,
then press button "3". Now the thermostat will
save the modifi ed parameters and will auto-
matically exit the parameter menu.
N.B. The thermostat will send the switch-on/-off
controls for the three fans and the two valves
to the actuator to a fi xed rate of 1 minute.
Index
Parameter
P01
Type of system
P02
External probe
P03
Display
visualization
P04
"Summer" valve
type
P05
"Winter" valve
type
P06
Auxiliary input
P07
Ambient
temperature
correction
P08
"Winter" lower
limit set-point
temperature
P09
"Winter" upper
limit set-point
temperature
11
Values
Preset
1-2
1
1-2-3-4-5
5
1-2
1
1-2
2
1-2
2
1-2-3
3
-4°C –+ 4°C
0
(step 0.1°C)
2 °C – 40°C
2,0 °C
(step 1°C)
2 °C – 40°C
40,0 °C
(step 1°C)
