Conel FLOW CUT BOX Manual page 47

167 MAX. 130
Behind partition
Shower tray connected
Alarm = 140 mm
On = 120 mm
Off = 45 mm
4
Pos Description
1
Removable panel KBN: ALPRO
2
Partition frame
3
Venting insert KBN: ABSVIS
In accordance with DIN 1986 - 100, the bottom level of the inlet lines from hand wash basins and
shower trays must be at a minimum height of 180 mm.
This ensures that the inlet line can run completely through a natural gradient and that no back-
wash occurs.
5
2%
DN 50
Figure 14 (2)
3
MAX. 350
DN 50
6
Pos Description
4
Shower tray
5
Secondary vent pipe option
6
Discharge flap valve
50
DN 50
47
