Button: press and hold for 2-7 seconds to reset or 7-12 seconds to restore to factory defaults:
RST (Reset)
Task
Reset the Switch
Restore to Defaults
: Mount the switch in a standard 19-inch equipment rack, on a desktop, or shelf; see the Install Guide.

Mounting

: Make sure that the cables are suitable for your operating environment. For fiber optic connections, use

Cabling

50/125 or 62.5/125 micron multimode fiber or 9/125 micron single-mode fiber. For copper connections, use UTP
for RJ-45 connections. For 1G bps connections use Category 5, 5e, 6, or 6a.
: The SM12DP2XA front panel has two power inputs for power

Connecting to Power

redundancy; the switch has a 100~240 VAC power socket for AC power Input and a
24-48 VDC power input via the terminal block. Using both Power Supplies provides
power failover when power supplies are connected to different circuits to. With fiber
and copper cabling completed, and AC and/or DC power applied, the port LEDs light,
the SYS LED flashes, the AC and/or DC LEDs light and the SYS LED goes from flashing
to steadily lit. See the Install Guide for Connecting to an AC and/or DC Power source.

Initial Switch Configuration

IP Address: 192.168.1.77, User Name: admin, and Password: admin.
Configuration: The command-line interface (CLI) is a text-based interface
CLI
that you can access the CLI through either a direct serial connection to the
device or a Telnet session. An RJ-45 cable is used for connecting a terminal or
terminal emulator to the SM12DP2XA RJ-45 port to access the CLI. Attach the
RJ-45 serial port on the switch front panel to the cable for Telnet/CLI
configuration. Attach the other end of the DB-9 cable to a PC running Telnet.
See the CLI Reference for initial switch configuration via CLI.
Configuration: The left-hand menu contains two main tabs (Switch and
Web UI
DMS) each with several sub-tabs for configuring and monitoring the switch's
major functions. The major Switch tab functions include System, Ports, DHCP,
Security, VLAN, QoS, Diagnostics, and Maintenance. The DMS (Device
Management System) functions are DMS Mode, Graphical Monitoring,
Management, and Maintenance. See the Web User Guide for initial switch
configuration via web browser.
: Related manuals include the SM12DP2XA Install Guide 33751, Web User Guide 33752, and

Related Information

CLI Reference 33753. For Drivers, Firmware, etc. go to the
For Manuals, Brochures, Data Sheets, etc. go to the
Transition Networks SFP
: Transition Networks | 10900 Red Circle Drive | Minnetonka, MN 55343 USA |
Contact
tel: +1.952.941.7600 | toll free: 1.800.526.9267 | fax: 952.941.2322 |
sales@transition.com |
33750 Rev. D
Press RST button for
2 ~ 7 seconds
7 ~ 12 seconds
: Initial switch configuration can be via CLI or web browser. The factory defaults are
webpage. See the DC Power Supply
techsupport@transition.com
https://www.transition.com
SYS LED Behavior
Blinking Green
Blinking Green
Product Support webpage (logon required).
Support Library (no logon required). For SFP manuals see
page for more information.
| customerservice@transition.com
SM12DP2XA Quick Start Guide
Port Status LED Behavior
All LEDs OFF
All LEDs stay ON
