Chapter 1 Options for the Cisco TelePresence System 500
Connect the audio for the DMP to the DMP Audio connection on the codec. See
connection.
Figure 1-2 Audio Connection for DMP
External Presentation
Presentation Source In
To configure the DMP audio for use with Cisco TelePresence, refer to the
Fixture and Configuring the Digital Media Player Audio"
the

Cisco TelePresence Presentation Codec

The Presentation Codec provides 30 frames per second capabilities to support full-motion video
presentations between Cisco TelePresence endpoints.

Parts List for Presentation Codec

Key Part Description
Presentation Codec, 800-28202-xx
1
Secondary (Presentation) codec
2 Handle/Mounting bracket
3 Rear cover
4
Mounting base
5
Left end cap
6 Top Cover
OL-16441-01
Display (optional)
Display
Document Camera
Cisco TelePresence System 500 Assembly, Use & Care, and Field Replaceable Unit
Network Presentation Audio (optional)
IP Phone
Camera
Base Station (optional)
(optional)
Part Number Qty
800-28202-xx 1
700-23917-01 2
700-27340-01 1
800-31148-01 1
700-27642-01 1
700-27343-01 1
Cisco TelePresence Presentation Codec
Figure 1-2
DMP Audio or
Headset or
Bluetooth-enabled
Microphone
Right Speaker
Left Speaker
"Testing the LEDs and Light
section of the "First-Time Setup"
Notes
Cisco TelePresence System
for the
chapter of
Guide.
1-3
