Chapter 5
Upgrading a Cisco TelePresence System 3000 to a Cisco TelePresence System 3200
Building the Second Row Table Assembly
Step 5
While one or more assistants keep the table legs steady, attach the Section 1 gutter panel to the Section
1 table legs.
Figure 5-10
Section 1 Gutter Panel
6
35
Cisco TelePresence System
5-19
OL-16441-01
