Industrial Electronic Devices
CHARACTERISTICS:
The HD67659-A1 is a PROFINET Slave / Ethernet Converter.
It allows the following characteristics:
Up to 500 bytes in reading and 500 bytes in writing on Ethernet side;
Two-directional information between Ethernet and PROFINET;
Mountable on 35mm Rail DIN;
Wide power supply input range: 8...24V AC or 12...35V DC;
Wide temperature range: -40°C / 85°C [-40°F / +185°F].
CONFIGURATION:
You need Compositor SW67659 software on your PC in order to perform the following:
Define the parameter of the PROFINET;
Define the parameter of the Ethernet/IP.
ADFweb.com Srl – IT31010 – Mareno – Treviso
User Manual PROFINET Slave / Ethernet - Converter
Document code: MN67659_ENG
INFO:
www.adfweb.com
Revision 1.000
Page 6 of 26
Phone +39.0438.30.91.31
