ETHERNET:
The Ethernet connection must be made using Connector3 or Connector4 of HD67659-A1 with at least a Category 5E cable. The maximum
length of the cable should not exceed 100m. The cable has to conform to the T568 norms relative to connections in cat.5 up to 100 Mbps. To
connect the device to an Hub/Switch is recommended the use of a straight cable, to connect the device to a PC/PLC/other is recommended
the use of a cross cable.
ADFweb.com Srl – IT31010 – Mareno – Treviso
User Manual PROFINET Slave / Ethernet - Converter
Document code: MN67659_ENG
Connector3:
Connector4:
Ethernet1 port
Ethernet2 port
(RJ45 Plug)
(RJ45 Plug)
INFO:
www.adfweb.com
Revision 1.000
Page 10 of 26
