DIMENSIONING

9.3 Technical data of the COMbIVERT F5 AIC devices

Max. precharging AIC at an ambient temperature T
Corresponding higher charging currents are expected at higher mains voltages. In this
case please contact KEB!
Size
S C
int
AIC kVA uF
14 11 820
16 23 1260
18 35 1800
20 52 3900
22 80 4950
24 125 8250
26 173 11700
27 208 14100
28 256 19800
29 319 19800
30 395 39600
33 554 59400
34 616 39600
38 1005 59400
Legend
S Apparent power
Internal capacity
Cint
Cextmax Maximum, connectable capacity
Load-shunt
R
Table 20: Technical data of KEB COMBIVERT F5 AIC devices
Option precharging resistor =>
1)
NOTICE
C
ext_max
at U = 440V / 480V
R
uF Ω
– 20
– 10
– 20
40.000/35.000 2.5
40.000/35.000 2.5
35.000/30.000 2.5
33.000/27.000 2.5
30.000/24.000 2.5
27.000/20.000 5.8
27.000/20.000 5.8
140.000/110.000 5.8
1)
230.000/180.000 3.9
1)
140.000/110.000 5.8
1)
230.000/180.000 3.9
1)
„Additional precharging resistor at master-slave
A restart for AIC with NTC is allowed only after 5 minutes.
= 45°C and U
a
Max. exter- Max. total
nal charging charging
current current
at at
U = 440V / 480V U = 440V / 480V
A A
73 / 67 104
130 / 120 190
320 / 315 350
– 250/270
– 250/270
– 250/270
– 250/270
– 250/270
- 107/117
– 107/117
- 107/117
- 161/175
– 107/117
- 161/175
= 440V / 480V.
N_max
Notes
–
NTC as shunt
1)
1)
1)
1)
1)
operation".
61
